Durable Medical Direct Laryngoscope for Difficult Airway Management
Medical Direct Laryngoscope Applications
1. Clinical endotracheal intubation.
2. Simulation practice
3. Clinical teaching
4. Difficult airway intubation.
Direct Laryngoscope Specifications:
Medical Direct Laryngoscope main features:
1.Clear view: Large depth of field, no blind area for intubation.
2.High resolution: 2 million pixels camera and 3" TFT clear color screen.
3.Intelligent: Built-in memory card is capable for data storage and output.
4.Faster: Unique anti-fog function, convenient and ready to use, no need for preheating.
5.Durable: High precision manufacturing process, ergonomic design handle with long service life.
6.Convenient: Portable laryngoscope with taking pictures, video recording and frame freezing function.
7.Optimization: Large capacity imported rechargeable Li battery provides up to 6 hrs continuous usage.
8.Safety: Disposable sterilized blades packaging to prevent cross infection for medical care personnel and patients.
9.Versatile: Integrated design applies for anesthesiology, ICU,pediatrics,emergency department and ambulance for clinical tracheal intubation.
Do you have clients who want a endotracheal intubation solution with
better laryngoscope view?
Are you looking for a Disposable video laryngoscope?
Are you looking for a laryngoscope with disposable blades which could be applied for
anesthesia, emergency department and ICU, for clinical endotracheal intubation, simulated practice, clinical teaching etc?
How about a person help you to solve all the problems
and leave you to sit back and relax?
I am Larry from HaiyeMED: a Chinese direct laryngoscope reliable manufacturer.
You could email me by Larry@haiyemedical.com
or WhatsApp: +86 132 8980 5658
WHY US?
Certificates such as
CE, FDA, ISO 13485, ISO9001
are proofs of our quality.
All of the Video Assisted Laryngoscope are
fully inspected before shipment.
Medical Direct Laryngoscope Specification:
| Description |
Specification |
| Machine |
Product name |
video laryngoscope |
| Item weight |
225 g |
| Power |
<2W |
| Screen |
Screen size |
3 inch LCD |
| Resolution |
960*480 pixels (RGB) |
| Viewing angle |
≥70º |
| Screen tilt angle(back/forth) |
0 º~135 º |
| Screen rotation angle(left/right) |
0º～275º |
| Camera |
Illuminance |
≥3000 Lux |
| Resolution |
2 mega or 1600*1200 pixels |
| Viewing angle |
≥70º |
| Depth of field |
3～100mm |
| Anti-fog |
Yes |
| Image/Video function |
Image/ Video/ Freeze frame function |
Yes |
| Output |
USB & AV output |
| Memory type |
8GB Micro SD card |
| Battery |
Battery Type |
Rechargable Li-ion |
| Capacity |
3400 mAh |
| Charging cycles |
>800 times |
| Charging time |
<4 hrs |
| Continuous working time |
≥6 hrs |
| Power Adapter |
Charging Port |
Micro USB |
| Input |
100-240V, 50 Hz. |
| Output |
5V, 2000mA |
| Working condition |
Temparature |
5℃--40℃ |
| Humidity |
≤80% |
| Atmospheric pressure |
860hpa～1060hpa |
Medical Direct Laryngoscope Packaging: Anti-drop Protective case
Packaging Details : Carton, Standard export packing for video laryngoscope
Package size: 415*110*345 cm
Gross weight: 2.3 kg
Standard equipment contain :
1x Main machine
1x Camera systems
1x Disposable laryngoscope blades
1x Charger
1x Anti-drop suitcase with foam protect in carton
1x Operation manual and warranty card
